Tree Controls - Microscan MS-Q Imager User Manual

Tree Controls

Tree Controls

To make changes to configuration settings in the tree control menus:
1. Left click on the
to expand or collapse
the tree.
2. Double click on
the parameter and
click once in the
selection box to
view options.
3. Place your cursor
in the selection
box, scroll down to
the setting you
want to change
and click once on
the setting.
The imager must be in one of the modes below to communicate with ESP.
USB
Connect
USB
Mode
RS-232
Connect
RS-232
Mode
2-4
-
+/
4. Left click again on the open screen to complete the
selection.
5. Right click on the open screen and select Save to
Reader to implement the command in the imager.
MS-Q Imager User's Manual
