Mirroring

Mirroring allows the MS-Q to decode symbols that are reversed. When Mirroring is
enabled, all other decode functionality is disabled.
Note: Once the imager has been set to Mirroring On, it can only return to its default mode
by reading the Mirroring Off symbol below.
Mirroring On
Note: Mirrored symbols can be read on dark or light backgrounds (depending on the
current Symbol Background setting. See
Image Transform
In ESP, the Mirroring feature is part of the Image Transform command.
When Image Transform is set to Standard, Mirrored Image is disabled.
When Image Transform is set to Mirrored Image, the MS-Q's optics reverse the captured
image before attempting to decode.
Save
Settings
MS-Q Imager User's Manual
Mirroring Off (Default)
Symbol Background
Default Default
to USB to PS/2
Advanced Operations
on page 7-20.)
Clear
All Data
Clear
XML
Rules
7-23
