Tree Controls

To make changes to configuration settings in the tree control menus:
+/
1. Left click on the
to expand or collapse
the tree.
2. Double click on
the parameter and
click once in the
selection box to
view options.
3. Place your cursor
in the selection
box, scroll down to
the setting you
want to change
and click once on
the setting.
Hint: To see the underlying serial command that corresponds with each tree control item,
click on the item in the tree control and drag the mouse to the open screen. The command
will be displayed between angle brackets.
HS-51/HS-51X Wireless Handheld Reader User Manual
-
4. Left click again on the open screen to complete the
selection.
5. Right click on the open screen and select Save to
Reader to implement the command in the reader.
In this example, the command for
Read Cycle Timeout is shown.
Using ESP
2-3
