Laser Target - Microscan MS-Q Imager User Manual

Laser Target

In most applications the laser target will have no
effect on symbol readability. Laser settings are
typically a matter of user preference.
This will disable the laser target. The
LEDs and the ability to decode symbols
will not be affected.
Laser Target Off
Laser Target On
Laser Target Brightness
Read one of the following symbols to set the brightness of the laser target.
High (Default)
Laser Target by ESP
Note: Laser On Before Capture determines whether the laser target will be on or off just
before the MS-Q captures and image, and is disabled by default.
Save
Settings
MS-Q Imager User's Manual
Medium
Default Default
to USB to PS/2
I/O Parameters

Laser target

exit point
Low
Clear
All Data
Clear
XML
Rules
6-3
