Batch/Battery

Batch/Battery

See Batch/Battery Interface
The battery automatically charges every time a cable interface is attached to the imager
and the host is powered-on.
The RS-232 interface power adapter must be plugged into a wall socket for the battery to
charge.
In USB and PS/2 interfaces, the imager and battery draw their current from the host
computer.
Typical Battery Charge Times
USB and PS/2
6 to 8 hours
Typical Battery Usage when not connected to the host:
• Up to 8 hours Standby
• Up to 4,000 reads
Batch/Battery Communication Indicators
Imager Activity
Successful Decode and
Data Storage
Batch Memory Full
a. When power is supplied via cable, the LED will remain green whenever the imager is active.
Important: When the memory LED turns RED, you must download or data will be lost.
4-16
on page 1-10 for instructions on installing the battery.
RS-232 Battery Charger
6 to 8 hours 4 hours
Memory LED
(LEFT indicator)
Memory Status
Solid RED
a
Battery LED
(RIGHT indicator)
None
None
MS-Q Imager User's Manual
Sound
1 beep
3 beeps
