EZ Mode

EZ Mode

The EZ Mode screen is the first thing you will see when you start ESP. EZ Mode will help
you get your imager up and running quickly, and will acquaint you with the ESP interface.
2-2
The EZ Mode toolbar allows you to switch to
App Mode, check your connection parameters,
and to switch models.
The Taking Pictures dropdown menu allows you to
choose which trigger will activate an image capture:
Handle Trigger, Right Button, or Left Button.
When an image is captured, it is displayed here
as a split view that shows both the near field
and far field images. Double click this image to
view it in a larger format. Click Save Image to
save it to a location of your choice.
The Decode button
allows you to begin
capturing images
and displaying
decoded symbol
data right away.
