UII Mode Features

UII-Only Enabled
UII-Only Enabled
with Error Messaging
UII Enabled with
Pass Through
UII Enabled with
Error Messaging
and Pass Through
UII Mode Settings
The following symbols control UII functions:
UII-Only
Enabled
UII Enabled
with Pass Through
Save
Settings
10-4
Allows the imager to read only UII message streams encoded
in ECC 200 Data Matrix symbols and to send the UII output to
the host computer. The imager will not read any other symbol
data when UII-Only is enabled.
Allows the imager to read only UII message streams encoded in
ECC 200 Data Matrix symbols and to send the UII output to the
host computer. In addition, the imager will send an error message
to the host if the UII message stream is invalid.
Allows both UII-encoded symbols and non-UII symbols to be
decoded and sent to the host.
Allows the imager to decode UII symbols and non-UII symbols, and
to provide error messages if the UII message stream is invalid.
UII-Only Enabled with
Error Messaging
UII Enabled with Error
Messaging and Pass Through
Default
to USB
Unique Item Identifiers
UII Disabled (Default)
Clear
Default
All Data
to PS/2
MS-Q Imager User's Manual
Clear
XML
Rules
