Microscan MS-Q Imager User Manual page 210

Configuration Symbols
Laser Off, Visible LEDs Off,
IR LEDs On at 100%
USB Battery Charge Mode
RS-232 Connect Mode
RS-232 Default
Settings Mode
Save
Settings
A-40
Laser On, Visible LEDs Off,
IR LEDs On at 100%
Default to Previous
Settings (Disable USB
Battery Charge Mode)
USB Connect Mode
Default
to USB
Laser Off, All LEDs On
at 100%
Laser Off, Control IR
Separately in Both Fields
Enable MIL-STD-130M
Default
to PS/2
MS-Q Imager User's Manual
Laser On, All LEDs On
at 100%
Laser On, Control IR
Separately in Both Fields
Enable MIL-STD-130N
Clear
Clear
All Data
XML
Rules
