Reading Symbols (100 Series)
• For best results, begin triggering before the LightRay Optic has come in contact with the
surface or substrate.
• Center the symbol in the LightRay Optic guide's cutout.
Guide
Reading Symbols (200 Series)
• For best results, begin triggering before the LightRay Optic has come in contact with the
surface or substrate.
• Position the symbol equidistant from both of the 200 Series LightRay Optic's guides.
Guides
