Send

The Send function allows you to enter text commands and then send them to the imager.
(See Text Commands
For example, suppose you want to enable the imager's laser target. To enable the target
using a text command, you would enter "P%0f3" (the command string that activates the
laser target) in the text field and click Send.
Type text commands in
the text field and then
click the Send button to
initiate. Clicking Send
repeatedly will initiate the
command repeatedly.
Once text commands are initiated, they are saved in a dropdown menu that can be
accessed by clicking the arrow to the right of the text field.
You can also send the current command repeatedly by clicking the Send button repeatedly.
8-4
on page 4-24.)
Click here to access the
dropdown menu of stored
text commands.
