Symbol Background

Symbol Background

"Symbol Background" refers to the color of the substrate on which a symbol is printed or
marked. In the default state, Reverse Background On means that both types of symbols,
dark-on-light and light-on-dark, will be read. Reverse Background Off will speed up
image processing if only dark symbols on light backgrounds are being read.
Reverse Background On (Default)
Reverse Background Off
Sample Data Matrix Symbol (Light Background)
Sample Data Matrix Symbol (Dark Background)
Save
Settings
7-20
Default Default
to USB to PS/2
Clear
Clear
All Data
XML
Rules
MS-Q Imager User's Manual
