Quick Start Guide

This Quick Start Guide provides a brief overview for fi rst use of the 788T/788T-SSD. For detailed operating
instructions refer to the 788T/788T-SSD User Guide and Technical Information.
1. Connect the supplied AC-to-DC power supply to the DC connector on the Right Panel.
2. Attach the supplied Li-ion rechargeable battery to the recorder, being certain to line up the battery
contacts with the battery compartment mounting pins. Rotate the battery lock to secure the battery in
place.
The included battery must be charged for six hours prior to initial use.
The 788T will charge the L-Mount battery when DC is connected.
3. Connect analog microphone or line sources. Please refer to the 788T/788T-SSD User Guide and Tech-
nical Information for connections with digital audio sources.
4. Connect headphones to either the 1/4-inch or 1/8-inch headphone output on the Right Panel.
