788T/788T-SSD User Guide and Technical Information
CS-W
CS- MAN
XL-1B
XL-2
XL-2F
XL-4
XL-B2
XL-BNC
XL-DVDRAM
XL-H
XL-LB2
XL-LCD
XL-LL
XL-LX
XL-NPH
XL-WPH3
112
v. 1.71 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Removable accessory case for the CS-4 Production Case. Designed to
hold wireless transmitters and receivers and provides the appropriate
cable routing for interconnection of wireless, mixers, and recorders.
Built for Sound Devices by CamRade.
Convenient, padded carry/storage case with handles, handy to store
wallets, keys and mobile phones; handcrafted in China.
TA3F to TA3F cable, connects the direct outputs of a Sound Devices
442 mixer to the 788T's analog inputs 5-8, also used to connect analog
outputs 1-4 to third-party devices with TA3M inputs, 12-inch.
TA3F to XLR-M cable, used to connect analog and digital outputs 1-4
to third-party devices with XLR-F inputs, 25-inch; package of two.
XLR-F to TA3F cable, used to connect microphones, mixers, and other
devices with XLR-M outputs to the 788T analog inputs 5-8, 25-inch;
package of two.
Bag of four (4) TA3-F-type connectors.
Removable, rechargeable, Li-ion battery; 7.2 V, 4600 mAh battery;
good to have several spares.
BNC to BNC cable, to connect word clock from external sources to the
788T for synchronizing the 788T; also used to sync external devices
from the word clock of the 788T.
An external bus-powered FireWire DVD Multi-drive. Based on the
slot-loading Panasonic UJ-85 drive mechanism, the XL-DVDRAM is
used with a 7-Series recorder to record directly to optical disk or as a
post-record storage volume.
Bare Hirose 4-pin locking DC connector (HR10-7P-4P).
5-pin LEMO to two (2) BNC cable, used to jam to and from video
cameras, 60-inch.
Protective, clear Lexan LCD cover for 7-Series Digital Recorders. Pro-
tects the LCD glass from scratches and water. Kit of four covers.
5-pin LEMO to 5-pin LEMO cable, used to connect the 788T time code
circuit to Ambient time code sync boxes, slates, and controllers or to
jam one 788T to another time code equipped 7-Series recorder; ad-
ditionally used to jam Aaton cameras from the 788T, 20-inch coiled,
55-inch full extension..
5-pin LEMO to XLR-M and XLR-F cable, used to connect the time code
output to SMTPE time code inputs and outputs, 25-inch to XLR-M,
14-inch to XLR-F.
NP-type battery cup with 24-inch cable terminated in Hirose 4-pin
locking DC connector (HR10-7P-4P) at equipment end.
AC to DC Power Supply (in-line) 100 - 240V 50/60 Hz input, 12 VDC
3.75 A (45 W) output, Hirose 4-pin DC plug. Supplied with 3-pin IEC
cord for use in North America and Japan. It is always good to have a
spare.
