# Setup Name
65 LCD: Backlight Mode
66 LCD: Scrolling Direction
67 Meter: Ballistics
68 Meter: Peak Hold Time
69 Meter: Input Peak Threshold
70 Meter: Input LED Ring Mode
71 Meter: Stealth Mode
72 HP: Rotary Switch Function
73 HP: Monitor Modes
788T/788T-SSD User Guide and Technical Information
Description
Enables or disables the LCD
backlight color from indicating that
the 788T is in Record, Playback, or
Standby.
Defines the direction in which the
Multi-Function Rotary Switch will
navigate throughout the 788T.
Selects among three different meter
ballistics settings
Adjusts the duration for which the
peak LED stays illuminated.
Sets the level in which the Input
Activity Ring LEDS will illuminate red.
Enables or disables Input Activity
Ring LEDs by color.
Enables the LEDs to toggle On and
Off with the LCD BACKLIGHT.
Selects the function activated when
the Multi-Function Rotary Switch
is pressed in while in Record and
Playback.
Selects the modes and the sequence
in which they appear in the Head-
phone Source Display.
Options
• White/Green/Red
• Red on Record Only
• Green on Play Only
• White Only
• Normal
• Reverse
• VU only
• Peak only
• Peak + VU
0 to 5 seconds adjustable in increments of
.1 sec
Selectable from -1 to -20 dBFS in 1 dB incre-
ments
• Red and Green enabled
• Red only enabled
• Green only enabled
• Red and Green Off
• Off
• On
• Disabled:
pressing in on the switch, makes no change to
the headphone matrix.
• Selects Favorite Mode:
in Record and Playback, pressing in on the
switch will change the headphone source
immediately to the favorite selected in HP:
Favorite Mode.
• Playback Drive Select
pressing in on the switch toggles between the
available storage media for Playback.
Inputs 1,2 Inputs 7,8 (MS)
Inputs 3,4 Tracks L,R (MS)
Inputs 5,6 Tracks A,B (MS)
Inputs 7,8 Tracks C,D (MS)
Tracks L,R Tracks E,F (MS)
Tracks A,B Tracks G,H (MS)
Tracks C,D Tracks X1,X2 (MS)
Tracks E,F Inputs 1-4
Tracks G,H Inputs 1-6
Tracks X1,X2 Inputs 1-8
Input 1 Tracks LA, RB
Input 2 Tracks LAC, RBD
Input 3 Tracks LACE, RBDF
Input 4 Tracks LACEG,RBDFH
Input 5 Tracks LACEGx1,RBDFHx2
Input 6 Tracks LRAB
Input 7 Tracks LRABCD
Input 8 Tracks LRABCDEF
Track L Tracks LRABCDEFGH
Track R Tracks LRABCDEFGHX1X2
Track A Tracks LR
Track B Tracks LRA
Track C Tracks LRB
Track D Tracks LRC
Track E Tracks LRD
Track F Tracks LRE
Track G Tracks LRF
Track H Tracks LRG
Track X1 Tracks LRH
Track X2 Tracks LRX1
Inputs 1,2 (MS) Tracks LRX2
Inputs 3,4 (MS) Input B-format stereo
Inputs 5,6 (MS) Track B-format stereo
Factory
Default
White/Green/Red
Normal
Peak + VU
0 seconds
-3 dBFS
Red and Green
enabled
Off
Selects Favorite
Mode
1) Tracks L,R
2) Tracks X1,X2
3) Tracks L
4) Tracks R
5) Tracks A
6) Tracks B
7) Tracks C
8) Tracks D
9) Tracks E
10) Tracks F
11) Tracks G
12) Tracks H
13) Tracks X1
14) Tracks X2
15) Tracks LRAB-
CDEFGHX1X2
16) Inputs 1,2
17) Inputs 3,4
18) Inputs 5,6
19) Inputs 7,8
20) Input 1
21) Input 2
22) Input 3
23) Input 4
24) Input 5
25) Input 6
26) Input 7
27) Input 8
28) Inputs1-8, 1-8
101
