Track Routing View

The screen below is the Track Routing View, it appears if the ROUTING (Rewind) Key is selected.
7
Track Routing
7)
Displays all inputs currently routed to
the given track. Rotate the Multi-Func-
tion Rotary Switch to move the selec-
tor box. Press in on the Multi-Function
Rotary Switch to route an Input to the
Track. Pre- or post-fade routing is ap-
plied as it is defi ned in the Input Set-
tings Window or the Setup Menu.

Track-to-Media View

The screen below is the Track-to-Media View, it appears if the MEDIA (Fast Forward) Key is selected.
9
Track-to-Media Routing
9)
Displays which media the given track
will be recorded to. Rotate the Multi-
Function Rotary Switch to move the
selector box. Press in on the Multi-Func-
tion Rotary Switch to toggle the routing
of the track to CompactFlash, Internal
Drive, or External media respectively.
Tracks will only be written to a given
media if it is selected in the Setup Menu
option Rec: Media Select, regardless of
it's Track-to-Media routing status.
788T/788T-SSD User Guide and Technical Information
8
Track Level Meters View
8)
Press the Rewind key to return to the
Track Level Meters Window.
10
Track Level Meters View
10)
Press the Rewind key to return to the
Track Level Meters Window.
