788T/788T-SSD User Guide and Technical Information
# Setup Name
18 Input: Linking, MS
19 Input: Front Panel Controls
20 Input: Limiter Threshold
21 Input: Limiter Recovery
22 Input: Limiter Knee
Input: Low Cut Slope
23
24 Input 1: Delay
25 Input 2: Delay
26 Input 3: Delay
27 Input 4: Delay
28 Input 5: Delay
29 Input 6: Delay
30 Input 7: Delay
31 Input 8: Delay
32 Input: PFL Function
33 File: Marker Mode
98
v. 1.71 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Description
Selects whether the input levels
are controlled independently, as
stereo pairs, with or without mid-side
decoding, or multiple inputs grouped
together.
Sets the Input Gain Potentiometers to
act as Faders or Trims. When set to
Fader Controls, the Multifunction Ro-
tary Switch will control the trim level
of the input from the Input Settings
Window. When set to Trim Controls,
the gain pots will only effect trim level.
This menu option is unavailable when
the CL-8 is connected.
Selects the threshold at which the in-
put limiters will become active across
all inputs where the input limiter has
been enabled in the Input Settings
Window.
Adjusts the recovery time of the
limiter in milliseconds.
This selects the response charac-
teristic of the limiters as the Limiter
threshold is reached.
Selects the amount of slope of the
high-pass (low cut) filter. Frequency
roll off point is selectable in the Input
Settings Window from 40 to 320 Hz in
10 Hz increments.
Sets a digital delay for each input.
Can be used to compensate for delay
in various digital wireless microphone
units or digital processors.
Sets the headphone monitor behavior
when an input is selected using the
Input Selector Switch. When enabled,
the input will be soloed in the head-
phone monitor. When disabled, the
Input Settings Window will appear but
the headphone monitor will remain
unaffected.
Enables the user to set cue points
or begin recording a new take by
pressing the REC key while in Record
mode.
Options
• Unlinked • 1-2, 3-4, 5-6, 7-8
• 1-2 • 1-2MS
• 1-4 • 3-4MS
• 1-6 • 5-6MS
• 1-8 • 7-8MS
• 3-4 • 1-2MS, 3-4MS
• 5-6 • 1-2MS, 3-4MS, 5-6MS
• 7-8 • 1-2MS, 3-4MS, 5-6MS, 7-8MS
• 5-6, 7-8
• 1-2, 3-4
• 1-2, 3-4, 5-6
• Trim Controls
• Fader Controls
-12 to -2 dBFS attenuated by .1 dB incre-
ments
50 to 2000 msec adjustable in 10 msec incre-
ments
• Hard-Knee
• Soft-Knee
• 6 dB/oct
• 12 dB/oct
0 to 30 milliseconds, 0.1 mS increments
• Enable PFL
• Disable PFL
• Disable PFL with CL-8 Connected
• Markers disabled
REC key does nothing when pressed in
Record mode.
• New Cue
Cue markers are set every time the REC key
is pressed in Record mode.
• New File
A new file is started with each press of the
REC key, the take counter is increased by one.
Factory
Default
Unlinked
Trim Controls
-6 dBFS
200 msec
Hard-Knee
12 dB/oct
Input 1 = 0 mS
Input 2 = 0 mS
Input 3 = 0 mS
Input 4 = 0 mS
Input 5 = 0 mS
Input 6 = 0 mS
Input 7 = 0 mS
Input 8 = 0 mS
Enable PFL
New File
