788T/788T-SSD User Guide and Technical Information
# Setup Name
74 HP: Favorite Mode
75 HP: Playback Mode
76 HP: Warning Bell Level
77 HP: Rec/Stop Bell
78 HP: Power Up Gain
79 Tone: Level
80 Tone: Frequency
Tone: Mode
81
82 Tone: Record Lock
83 Slate Mic: Mode
84 Drive: Speed Tests
85 Balance Cal
86 Power: Ext Low Batt Volt
87 Power: Ext Power Function
88 Power: Battery Charger
89 Keyboard/Logic In: Assign
90 CL-1: Reprogram
91 CL-1: Logic Out Assign
102
v. 1.71 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Description
Selects the audio source monitored
when the Multi-Function Rotary
Switch is pressed during Record or
Playback.
Selects the audio source sent to the
headphones during Playback.
Sets the output level of the warning
bell.
Alerts the user with one beep at the
start of recording and two beeps
when the recording is stopped
Selects the level at which the
headphone gain level will be set upon
power up.
Sets the reference tone's output level.
Sets the tone oscillator frequency.
Selects the reference tone's
destination(s).
Sets the Tone key to be either avail-
able or locked while in Record Mode.
Slate Mic is only enabled when the
CL-8 is attached.
Performs a write/read speed test on
the internal drive, CompactFlash, and
external drives. Data transfer speed is
measured in KB/s.
Calibrates the center position of
the even input (2,4,6,8) pots when
used as the balance control for MS
recording.
Sets the external low battery warning
point. The internal low battery level is
not user-adjustable.
Controls the behavior of the unit
when power is applied to the external
DC jack.
Determines when the Sony L-Mount
will charge when connected to
external power.
Define functionality and keyboard
shortcuts when using the USB key-
board and Logic Input.
The CL-1 has its own firmware which
is supplied from the 788T. This utility
updates the CL-1 firmware.
Each logic output pin can be as-
signed to go high when the unit is in
the selected mode. Logic input over-
rides logic output selection.
Options
Any of the HP: Monitor Modes can be selected
as the HP: Favorite Mode. See the above
chart for options.
• No change
• Same options listed in HP: Monitor Modes
off, −60 to –12 dBFS in 1 dB steps
• Disabled
• Enabled
• Last Gain
• Midpoint Gain (0 dB)
• Off
−40 to 0 dBFS in 1 dB steps
100–10,000 Hz in 10 Hz steps
• Disabled
• To record tracks only
• To outputs only
• To record tracks and outputs
• Enabled While Recording
• Locked While Recording
• Disabled
• To record tracks and outputs
Caution: Drive test will disable processing and
mute outputs for duration of test. Outputs will
not return until test is exited.
Place balance control to center and press to
select.
10.0–18.0 VDC, 0.1 V steps
• Do Nothing
• Power On Unit
• Power On and Start Record
• Power On/Off unit
• Power On/Off unit and Record
• Off
• Charge only when unit is on
• Charge only when unit is off
• Always charge
• Undefined
• Stop
• Play
• Pause
• Record
Factory
Default
Tracks L,R
Tracks L,R
-30 dBFS
Enabled
Last Gain
-20 dBFS
1000 Hz
To record tracks
and outputs
Locked While
Recording
To record tracks
and outputs
10.0 Volts
Do Nothing
Always charge
Undefined
