788T/788T-SSD User Guide and Technical Information
• Mid-Level / Tape (Roll) Folder – can be selected as a Roll folder with user-selected name or as
a <DAILY> folder, or not used. The name of this folder is inserted in the <TAPE> (Roll) fi eld of
the iXML and bEXT chunks.
If a TOP-LEVEL folder is in use, the MID-LEVEL folder will be a sub-folder of the TOP-LEVEL
folder. If no TOP-LEVEL folder is used, the MID-LEVEL folder will reside at the drive's root. If
set to <DAILY> a new folder will be created daily. When recording past midnight the 788T will
prompt to make to a new daily folder.
• Bottom-Level / Scene Folder – can be selected as a <SCENE> folder which will use the name
generated from the REC: SCENE NAME/NUMBER Setup Menu, as a user-selected name, or not
used at all.
If no upper-level folder is in use, the BOTTOM-LEVEL folder will reside at drive's root. If the
MID-LEVEL and/or TOP-LEVEL are in use the BOTTOM-LEVEL folder will be a sub-folder.
Example: If a daily Folder is desired, set the TOP-LEVEL to <NONE>, the MID-LEVEL folder to
<DAILY>, and the BOTTOM-LEVEL to <NONE>. This will generate a Daily Folder in the root directory
with fi les directly inside the folder.
A hierarchical view of fi les generated by the 788T is below.
Example:

The Drive Directory (File Viewer)

From within the Drive Directory, navigate between storage media, folders, and fi les. View fi le prop-
erties and select fi les for playback. The Drive Directory always exits to the main LCD display wheth-
er entered from the Setup Menu or via the Take List.
The left side of the File Viewer displays storage media, folders, and fi les. The top line displays the di-
rectory path in the form of DRIVE\FOLDER NAME and the right side displays fi le or folder proper-
ties depending on what is selected on the left hand side. File and folder names are listed in the order
in which they were recorded.
70
v. 1.71 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
788T
FALSETAKES
SOUNDDEV
TRASH
TOP-LEVEL
MID-LEVEL
BOTTOM-LEVEL
788T
FALSETAKES
SOUNDDEV
TRASH
PROJECT
07Y01M15
SCENE
NAMET01.WAV
NAMET02.WAV
The FALSETAKES, SOUNDDEV, and TRASH folders are automatically
generated. SOUNDDEV is not viewable from the 788T File Viewer.
A TOP-LEVEL folder sits in the root directory. This folder can be
negated by choosing <None> in the menu File: Folder Options.
A MID-LEVEL folder can be used as a sub-folder. This folder can be
selected to be a <Daily> folder in the menu File: Folder Options.
A BOTTOM-LEVEL folder could also be used as a sub-folder. This
folder can be selected to be a <Scene> folder in the menu File: Folder
Options.
This is a TOP-LEVEL folder named PROJECT activated in the menu
File: Folder Options.
This is a MID-LEVEL folder set to <Daily> from the menu File: Folder
Options.
This is a BOTTOM-LEVEL folder set to <Scene> from the menu
File: Folder Options.
These two files are title NAME in the menu
Rec: Scene Name/Number.
