788T/788T-SSD User Guide and Technical Information
Specifi cations
System
Sampling Frequency
Internal Data Path
and Processing
A/D, D/A Converters
A/D Dynamic Range
D/A Dynamic Range
Metering
Input to Output Delay

Analog Input

(all measurements at Fs 48 kHz, 24 bit unless noted)
Frequency Response
THD + Noise
Gain
(input dBu to −20 dBFS)
Input Impedance
Input Clipping Level
Input Topology
Gain Matching
Common Mode Rejection Ratio
High-Pass Filters
Mic Powering
(each analog Input selectable)
Mic/Line Input Limiters
Output Analog
Line Output Clipping Level
Attenuation & Resolution
Output Topology
Inputs/Outputs – Digital
AES3
Balanced AES out 1-4 on TA3 connector; Balanced AES out 5-6 on DE-15 connector110 ohm, 2 V p-p, AES and S/
PDIF compatible with RCA adaptor Balanced AES in 1-8 on DE-15 connector110 ohm, 2 V p-p, AES and S/PDIF
compatible with RCA adaptor
AES42
AES42 Mode 1 operating system, provides +10 V Digital Phantom Power to Digital Input pairs (menu-selectable).
106
v. 1.71
Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
internal: 32, 44.1, 47.952, 48, 48.048, 88.2, 96, 96.096
external clocking: 32–48.048 kHz via word clock or digital inputs
AES/EBU inputs can accept signals from 32-192 kHz when sync reference = internal (SRC enabled).
32 bit, 192 dB dynamic range
24 bit, 96.096 kHz maximum sampling rate
123 dB, A-weighted bandwidth
120 dB, 20 Hz–22 kHz bandwidth
114 dB, A-weighted bandwidth
111 dB, 20 Hz–22 kHz bandwidth
112-segment (8 x 14), sunlight-viewable,
selectable peak, VU, or peak (with or without peak hold) with VU ballistics, variable brightness
1.4 msec, from XLR Analog Inputs to all Outputs (with 0.0 Delay selected in the Setup Menu)
Mic or Line: 10 Hz–20 kHz, +0.1, −0.5 dB (gain controls centered)
Mic: 0.004% max (1 kHz, 22 Hz–22 kHz BW, gain control down, −15 dBu input)
Line: 0.004% max (1 kHz, 22 Hz–22 kHz BW, gain control down, +16 dBu input)
Mic: Off, 0 to 76 dB
Line: Off, -26 to 50 dB
Mic (XLR and TA3): 3.3k ohm
Line (XLR and TA3): 3.3k ohm
Mic: +8 dBu minimum (gain = 10 dB)
Line: + 26 dB minimum (gain = 0 dB)
Mic and Line: fully electronically balanced, RF, ESD, short, and overload protected;
pin-2 hot, pin-3 cold
Mic/Line inputs: ±0.1 dB, channel-to-channel while linked
Mic: 40 dB minimum at 80 Hz
40-320 Hz in 10Hz steps @ 6/12 dB/oct (Setup Menu selectable)
48 V phantom through 6.8k resistors, 10 mA per mic available, menu-selected per input in
Mic- or Line-level positions
Variable threshold -12 to -2 dBFS; Infinite:1 limiting ratio, 2 msec attack time, menu-se-
lectable release time 50-2000 msec, menu-selectable hard- or soft-knee (soft-knee starts
approximately 6 dB below setting)..
+24 dBu, 10k ohm load
0–20 dB, 1 dB increments
Line: fully electronically-balanced, RF, ESD, short, and overload protected; pin-2 driven hot,
pin-3 driven cold; let pin-3 float for unbalanced connections.
