Input Settings View

From the Input Settings View apply various input settings to any input. Press the A button to en-
able/disable the Limiter. Press the B button to enable/disable the High-Pass Filter. Simultaneously
press the A and B buttons to invert the polarity of the input.
While in the Input Settings View the L, R, Aux 1, and Aux 2 LED indicators are disabled. Limiter and
High-Pass Filter LEDs illuminate solid yellow when the respective input setting is enabled. Input
Polarity LEDs illuminate solid blue when the input's polarity has been inverted. The LEDs will fl ash
respectively on each input if the Limiter and High-Pass Filter are disabled and Input Polarity is nor-
mal. Press the ALT button to return to the Main View.

Slate Mic

The CL-8 activates the 788T's built-in Slate Mic. Slate microphones are commonly used for notation
and communication purposes. The audio performance of the 788T's built in Slate Mic is not suitable
for critical recording applications. The Slate Mic signal is sent to all outputs and record tracks. When
activated the Slate Mic overrides all available inputs and record tracks. The 788T Input Activity Ring
LEDs will illuminate solid yellow when the Slate Mic is active. In the Setup Menu, the Slate Mic can
be disabled to prevent unintended activation.
The Slate Mic gain level can be attenuated from -46 to 6 dB in 1 dB increments. Follow these steps to
attenuate the gain of the Slate Mic.
1. Navigate to the 788T's Main LCD Screen.
2. Press and hold the SLATE button on the CL-8's Left Panel.
3. Turn the Multi Function Rotary Switch to adjust the gain. The gain level is momentarily displayed in
the Sample Rate fi eld of the LCD display.
4. Release the SLATE button to deactivate the Slate Mic.
