Fast-Forward Key
16)
Performs fast-forward (FF) scrubbing
through the played fi le when pressed in
playback and play-pause mode. Play-
pause indicated by fl ashing A-time on
LCD. Fast forward rate increases the lon-
ger the key is held. In play-stop mode
(indicated by fl ashing fi lename on LCD)
selects the next fi le in the record folder
(either daily folder or main folder).
LCD Backlight Key
17)
Press to toggle between Level Meter
LEDs to View 1 (Tracks C - F) and View
2 (Tracks G, H, X1, X2). Press and hold
then Press the Multifunction Rotary
Switch to toggle the LCD and Front
Panel soft key backlighting. Hold the
LCD Backlight key and turn the Multi-
Function Rotary Switch to adjust the
brightness of LEDs. In the Setup Menu
the LCD Backlight key functions as the
cancel and exit key.
Media Activity LEDs
18)
Indicates storage media activity. IN
(internal drive), CF (CompactFlash), EX
(external FireWire device). The LED il-
luminates green when the storage media
is ready, illuminates yellow when the
storage media is writing/reading and
while connected to a computer, and illu-
minates red when the storage media has
encountered an error, if the drive has
less than one minute of recording time
left, or when running the Drive Repair
utility.
788T/788T-SSD User Guide and Technical Information
Stop/Pause Key
19)
Momentarily press and hold this key to
stop recording. In playback mode, a sin-
gle press pauses playback (play-pause),
allowing audio scrubbing with the FF
and REW keys. Another press of the key
enters play-stop mode where the FF and
REW keys select fi les for playback from
the current directory, the fi lename and
time display fl ash to indicate that a new
fi le has been selected. One more press of
the key exits playback mode.
Pressing the STOP key whilst in stop
mode displays the name of the next fi le
to be recorded in the LCD. In the Setup
Menu the STOP key is also used to exit
from any menu, returning to the main
display.
Record Key
20)
Press to begin recording. The 788T is
a record-priority device; pressing this
key starts recording and discontinues
all other functions, except fi le opera-
tions. The REC key will illuminate red
when the 788T is actively recording. If
the selected storage media is not ready
to begin recording a new fi le, the REC
key will fl ash red until the recording has
begun. Pressing the REC key during re-
cording can set a cue marker, start a new
fi le, as selected in the Setup Menu.
Record LED
21)
Illuminates red when record mode is
active.
