788T/788T-SSD User Guide and Technical Information
5. Press and hold the PWR key for one second to power on.
6. INPUTS MUST BE ACTIVE TO BE RECORDED. Press in to release recessed Input Gain Controls.
Rotate the knob clockwise past the detent to turn on the input.
In the full counter-clockwise position, the input is not active and is not available for use.
7. To access the Input Settings Window for an input, momentarily move the Input Selector Switch in the
direction of the Input. This action also sends the input signal to the headphone monitor.
Input Setting Options:
Source (mic/line/digital)
Phantom (on/off)
High-Pass Filter (on/off)
Limiter (on/off)
Input-to-Track Routing
Mute (none / mute)
Polarity (normal / reverse)
4
v. 1.71 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
MENU
1 3 5 7
2 4 6 8
HDD
MENU
1 3 5 7
2 4 6 8
HDD
Press adjacent key to change the parameter.
788T
INPUT
ARM ARM
R C
L D
A E
B F
0
d BFS
REC
IN CF EX
788T
INPUT
ARM ARM
R C
L D
A E
B F
0
d BFS
REC
IN CF EX
1
Left for odd inputs
2
Right for even inputs
