788T/788T-SSD User Guide and Technical Information

Master Gain Levels View

L/R Meters
11)
Displays real time metering of Left and
Right Track Levels.
AUX Meters
12)
Displays real time metering of X1 and
X2 Track Levels.
L/R Master Gain
13)
Pressing the soft L/R (Rewind) key will
select the Left and Right Tracks Master
Gain level. Gain is attenuated from 0
to -60 dB in .1 dB increments using the
Multi Function Rotary Switch or the soft
up and down arrows. Press in on the
Multi Function Rotary Switch to return
to unity gain (0 dB).
22
v. 1.71 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
The screen below is the Master Gain Levels View, it appears if the LEVELS (Play) Key is selected.
11
13
12
14 15
Meters
14)
Press the soft METERS (Play) key to
return to the Track Level Meters View.
AUX Master Gain
15)
Pressing the soft AUX (Fast Forward)
key will select the Aux Tracks Master
Gain level. Gain is attenuated from 0
to -60 dB in .1 dB increments using the
Multi Function Rotary Switch or the soft
up and down arrows. Press in on the
Multi Function Rotary Switch to return
to unity gain (0 dB).
