Input/Output Ports and Switches

These ports are located on the bottom of the phone (see the figure on
Component
Reset Button
Link/Activity
Indicators
LAN Connector
Socket
PC Connector Socket
Power Adapter Input
Power Source
Selector (available on
some models)
Handset Cord Port
Headset Wire Port
Phone Overview
Input/Output Ports and Switches
Used to reset the phone to its factory set default values.
Indicates whether there is LAN/Intranet and/or PC activity.
Use this RJ-45 connector port to connect your phone to the LAN/WAN.
Use this RJ-45 connector port when only one LAN/WAN outlet is available in your
immediate vicinity. Connect your PC's LAN wire to this connection socket while the
phone is connected to the LAN/WAN.
Used to connect the AC power adapter to the phone to supply the required DC power
when PoE is unavailable.
Note: An AC power adapter supplying 5 VDC/ 2000 mA is required. It is not supplied
with the phone and must be ordered from the manufacturer only. The use of any other
power adapter will void the warranty.
• Adapter — Switch to this option when a power adapter is connected to the phone.
• PoE: Power over Ethernet — Switch to this option to enable power for the phone
over your LAN/WAN connection.
Note: This feature is not available for T207M/NP and T207S/NP models.
Connect the Handset cord to this RJ-9 port.
Connect the Headset to this RJ-9 port.
2.5mm diameter jack for different plug types.
).
