Input/Output Ports and Switches

These ports are located on the bottom of the phone (see the figure on
Component
Reset Button
Link/Activity
Indicators
LAN Connector
Socket
PC Connector Socket
Power Adapter Input
Power Source
Selector (available on
some models)
Handset Cord Port
Phone Overview
Input/Output Ports and Switches
Used to reset the phone to its factory set default values.
Caution:Resetting the phone will erase all of the defined settings.
Indicates whether there is LAN/Intranet and/or PC activity.
Use this RJ-45 connector port to connect your phone to the LAN/WAN.
Use this RJ-45 connector port when only one LAN/WAN outlet is available in your
immediate vicinity. Connect your PC's LAN wire to this connection socket while the
phone is connected to the LAN/WAN.
Used to connect the AC power adapter to the phone to supply the required DC power
when PoE is unavailable.
Note: An AC power adapter supplying 5VDC...2A maximum is required. It is not
supplied with the phone and must be ordered from the manufacturer only. The use of
any other power adapter will void the warranty.
• Adapter — Switch to this option when a power adapter is connected to the phone.
• PoE: Power over Ethernet — Switch to this option to enable power for the phone
over your LAN/WAN connection.
Note: This feature is not available for T207M/NP and T207S/NP models.
Connect the Handset cord to this RJ-9 port.
).
page 10
Description
8 T207M / T208M User Guide
