Using the Display Panel

The phone Display provides an easy-to-use control interface. On this display several different classes of function information
and controls are found. During normal operation the active function assumes control over the entire area of the display and all
of the soft keys. Meanwhile, the System Lines (1
(T208M only), station name and number, automatically change to relay pertinent information about telephony states and
operations, and the calling party's information.
Four soft keys located immediately below the display screen, act as triggers for any currently displayedphone function or
option. All of the information on the display panel (bottom line) continually changes to reflect options related to the current
state of the phone. In this manner, no matter which state the telephone is in (i.e. Idle, Ringing, etc.) the relevant option is
always next to and enabled by one of the soft keys.
Ring and Message
Waiting Indicator
Phone Overview
Using the Display Panel
st nd
and 2 lines) which usually, in idle state, include the time, date, site name
10:50 26 May 2007
er
User Name Station Numb
Msg Log Dir Fwd
T207M Display Panel
15
Time & Date
System Information Lines
Feature Options
Soft Keys
