Component Descriptions

The following table defines controls, buttons and keys found on the T207M/T208M.
Component
Dial Pad (Key Pad) Digit buttons used for dialing phone numbers or extension numbers.
T207M Display Displays pertinent calling/menu/line information, based on the phone status (e.g., idle, busy,
dialing...).
The display is composed of three lines (128x32 pixels): System lines (1
options (on 3
T208M Display Displays pertinent calling/menu/line information, based on the phone status (e.g., idle, busy,
dialing...).
The display is composed of six lines (128x64 pixels): System lines (1
function options (on 6
Handset Works as typical phone handset.
Headset Non-manufacturer headset purchased by customer (see
Hook Switch On-hook or off-hook for handset.
Handset Latch Used to catch the handset when wall mounted or for elevated (60° or higher) desktop mounts.
Loudspeaker Output sound device used in hands free operation, paging and ringing.
Microphone Input sound device used in hands free operation.
Ring and Message Lamp flashes at a slow rate, indicating that a message is waiting.
Waiting Lamp Lamp flashes at a faster rate (to the beat of the ring) when the phone is ringing.
Phone Overview
Component Descriptions
rd
line) according to phone status. See
th
line) according to phone status. See
11
Description
page 15.
st
, 2
page 16.
page 22, page
st nd
and 2 lines), and function
nd, rd, th th
3 4 and 5 lines), and
27, and page 239).
