Input/Output Ports and Switches

These ports are located on the bottom side of the phone.
Component
Internet Connector
Socket
PC Connector Socket
Power Adapter Input
Handset Cord Socket
Headset Wire Socket
Phone Overview
Input/Output Ports and Switches
Use this RJ-45 connector port to connect your phone to the LAN/WAN.
Use this RJ-45 connector port when only one LAN/WAN outlet is available in your immediate vicinity.
Connect your PC's LAN wire to this connection socket while the phone is connected to the LAN/WAN.
Used to connect the AC power adapter to the phone to supply the required DC power when
PoE is unavailable.
Note: An AC power adapter supplying
phone and must be ordered from the manufacturer only. The use of any other power adapter
will void the warranty.
Connect the Handset cord to this RJ-9 socket.
Connect the Headset to this RJ-9 socket.
Description
is required. It is not supplied with the
5VDC...2A maximum
8 T328 Executive IP Phone User Guide (Coral IPx/FlexiCom)
