Appendix B — Media Specifications

Media Roll Size

116
Media Roll
Core diameter (A), standard: 38-40 mm (1.5 inches), with
adapter:76.2 mm (3 inches)
Core Width: Must not protrude outside the media.
The media must be wound up on the core in such a way that the
printer can pull the end free.
Media Maximum Diameter (B): Tear-off and Cut-off: 213 mm
(8.38 inches). Peel-off and Batch takeup: 205 mm (8.07 inches).
Media width (C): Minimum: 25 mm(1.00 inches), maximum:
120 mm(4.72 inches)
The recommended media thickness is 60 to 170μm (2.4 to 6.7
mils). If thicker media is used, print quality may be reduced.
Media stiffness must be balanced against thickness to maintain
print quality. Media rolls to be loaded inside the printer should
be wound with the printable side facing outwards.
The media supply must not be exposed to dust, sand, or grit. Any
hard particles, however small, can damage the printhead.
