Intermec EasyCoder PX4i User Manual page 126

EasyCoder PX4i User's Guide (IPL Version)
Firmware
Firmware IPL v2.30
Operating System 13 scalable + 21 simulated bitmap
44
Smooth Fonts
Physical Measurements
Dimensions (W × 275 × 482 × 238 mm
L × H) (10.8 × 19.0 × 9.4 in)
Weight (excluding 12.85 kg (28.4 lbs)
media)
Ambient +5°C to +40°C (+41°F to +104°F)
Operating
Temperature
Storage -20°C to +70°C
Temperature (-4°F to +152°F)
10 to 90% non-condensing
Humidity
Electronics
Microprocessor 32 bit RISC
On-board Flash 2 sockets for 4MB or 8MB each
SIMMs Standard 1x 4MB
On-board 1 socket for 16MB
SDRAM SIMM Standard 16MB
Power Supply
AC Voltage 90 to 265 VAC, 45 to 65 Hz
PFC Regulation IEC 61000-3-2
Power Minimum 20W; Continuous printing,
Consumption average 125W; Peak 400W
Appendix A — Technical Data
111
