Tickets With Gaps (Gap Stock)

EasyCoder PX4i User's Guide (IPL Version)
a
b
c
e
d
(e) Detection Height
Recommended: 1.6 mm (0.06 inches)
Minimum: 1.27 mm (0.05 inches)
Maximum: 25.0 mm (0.98 inches)
Media Type Setup: Gap Stock
Note: Handle perforated media carefully to avoid rips or breaks
along the perforations. Broken or ripped perforations, particularly
at the edges, may cause the media to break or misfeed during
printing.
Appendix B — Media Specifications
(a) Media Width
Minimum: 25 mm (1.00 inches)
Maximum: 120 mm (4.72 inches)
(b) Liner Width
Minimum (without LTS): 8 mm (0.32
inches)
Minimum (with LTS):12 mm (0.47
inches) For more information, see
Taken Sensor" on page
Maximum: 6,143 mm (241 inches)
provided there is a sufficient amount of
free SDRAM memory
(c) LSS Detection Position: Variable, see
"Label Stop Sensor" on page
(d) Detection Length
The length of the detection slit
(excluding corner radii) must be a
minimum of 2.5 mm (0.10 inches) to
either side (right or left) of the label stop
sensor detection position.
"Label
81.
106.
119
