Media Roll Size; Core; Media - Intermec EasyCoder PF4i User Manual

Chapter B — Media Specifications

Media Roll Size

Core

Media

110
Diameter (A), standard: 38-40 mm (1.5 inches), with adapter:
76.2 mm (3 inches)
Width: Must not protrude outside the media.
The media must be wound up on the core in such a way that the
printer can pull the end free.
Diameter:
• Position 1
• Position 2
• Position 3
Maximum: 114.3 mm / 4.50 inches
Minimum (standard): 25 mm /1.00 inches
Minimum (Quick-Load): 40 mm / 1.57 inches
152 mm / 6.00 inches
203 mm / 8.00 inches
213 mm / 8.38 inches
EasyCoder PF4i User's Guide (IPL Version)
