Using the Web Browser Interface
Status Reporting Features
Figure 5-13.Example of Alert Log Detail View

The Status Bar

The Status Bar is displayed in the upper left corner of the web browser
interface screen. Figure 5-14 shows an expanded view of the status bar.
Figure 5-14. Example of the Status Bar
The Status bar consists of four objects:
■
5-20
Status Indicator
Status Indicator. Indicates, by icon, the severity of the most critical
alert in the current display of the Alert Log. This indicator can be one of
three shapes and colors as shown in the following table.
Most Critical Alert Description
Product Name
