Rack Mounting Procedure
The unit can be mounted on any of these optional rack systems, including:
•
•
To mount the scaler on a rack shelf, follow the instructions provided with the shelf
accessories.
Under-desk Mounting
Mount the unit under a desk or podium, using the optional Extron MBU 125 under-desk
mounting kit (part # 70-077-01) by following the instructions provided with the MBU 125
kit.
RSU 129: 9.5 inches deep, 1U rack shelf kit (part # 60-190-01)
RSU 126: 6 inches deep, 1U rack shelf kit (part # 60-190-10)
SSP 7.1 • Mounting
98
