Setup and Control
Software
The SSP 7.1 Setup and Control Software provides an intuitive, easy to operate, graphical
user interface that allows the user to configure the audio system quickly and efficiently. It
provides more options than the front panel. As selections are made, only the options that
are available for the current configuration are displayed by the software. Extron strongly
recommends using the SSP 7.1 Setup and Control Software for all configuration.
The program comes on a disk, supplied with the unit. It can also be downloaded, free of
charge, from the Extron Web site (www.extron.com).
The following sections describe:
•
•
•
•
•

Installing the SSP 7.1 Setup and Control Software

The minimum system requirements for installing the program on the computer are:
•
•
•
•
•
Insert the disk provided into the CD or DVD ROM drive of the computer. If the setup
program does not start automatically, run Launch.exe from the CD or DVD ROM directory
in Windows My Computer. Select the Software tab, locate the SSP 7.1 Setup and Control
Software, and click Install. Follow the on-screen instructions to install the program.
Alternatively, go to the
Software option in the left sidebar. Navigate to the SSP 7.1 Setup and Control Software
and click Download. Follow the on-screen instructions to install the program.
By default, the Installer program creates a C:\Program Files\Extron\SSP7.1 folder
to contain the SSP 7.1 Setup and Control Software. An icon may also be placed
on the Windows desktop.
Installing the SSP 7.1 Setup and Control Software
Live and Emulate Modes
Running the SSP 7.1 Setup and Control Software
SSP 7.1 Setup and Control Software Help File
Firmware Updates
Operating system — Microsoft
CPU — Intel
® Pentium ® II processor with a 400 MHz clock speed or faster
Hard disk space — At least 10 MB
Memory — At least 64 MB of RAM
Device connection — Serial COMM Port
Extron Web
Windows 2000 or higher
® ®
site, click on the Download tab, and click on the
SSP 7.1 • Setup and Control Software 22
