Command
Parametric EQ Filter Frequency Setting for each Output Channel
Set Frequency for each
filter and output channel
View Frequency for each
filter and output channel
Parametric EQ Filter Gain Setting for each Output Channel
Set Gain for each filter
and output channel
View Gain for each filter
and output channel
Parametric EQ Filter Q Setting for each Output Channel
Set Q value for each filter
and output channel
View Q value for each
filter and output channel
X@
NOTE:
— Audio Outputs (1-8): 1 = Left Front, 2 = Center, 3 = Right Front, 4 = Left Surround Side, 5 = Right Surround Side,
6 = Left Surround Back, 7 = Right Surround Back, 8 = Subwoofer
X4$
— Parametric EQ filter selection (1 to 9). Determines whether the corresponding frequency range is bypassed or not:
1 is the lowest frequency range, 9 is the highest frequency
X4%
— Parametric EQ filter frequency. Default values: 62 Hz (filter 1), 125 Hz (filter 2), 250 Hz (filter 3), 500 Hz (filter 4), 1000 Hz (filter
5), 2000 Hz (filter 6), 4000 Hz (filter 7), 8000 Hz (filter 8), 16000 Hz (filter 9)
X4^
— Parametric EQ Q value, multiplied by 1000 (from 707 to 15000; default 2000)
ASCII Command Response
(host to unit) (unit to host)
E X@ X4$ X4%
F * * SseF
}
SSE
E X@ X4$ }
F * SSE SseF
E X@ X4$ X4^
G * * SseG
}
SSE
E X@ X4$ }
G * SSE SseG
E X@ X4$ X4&
Q * * SseQ
}
SSE
E X@ X4$ }
Q * SSE SseQ
Additional Description
X@ X4$ X4%]
Sets the frequency for each filter and
* *
output channel
X@ X4$ X4%]
Shows the current frequency for each
* *
frequency and output channel
X@ X4$ X4^]
* * Sets the gain for each filter and output
channel
X@ X4$ X4^]
Shows the current gain for each filter
* *
and output channel
X@ X4$ X4&] Sets the Q value for each filter and
* *
output channel
X@ X4$ X4&]
* * Shows the current Q value for each filter
and output channel
