Speaker test sequence
To run an automatic test sequence
1. Select the Auto button. This sends a
two second test signal to each output
channel in the sequence shown in the
diagram at right. All other speakers
are muted. The test sequence cycles
through each speaker multiple times
until the test signal is switched off.
2.
Click on Off in the Select Signal Type
area to switch off the test signal and
end the test sequence.
To test the speakers manually:
1. Click Auto to deselect it.
2. Click the forward (>) or back (<) buttons to move forward or backward
through the sequence shown in the diagram below.
3. Click Off in the Select Signal Type area to switch off the test signal and
end the test sequence.
5.1 Setup 6.1 Setup
Left Front
channel
2 Sec
Center
channel
2 Sec
Right Front
channel
2 Sec
Right Surround
2 Sec
channel
Center Back
2 Sec 2 Sec
channel
2 Sec
Left Surround
channel
2 Sec
Subwoofer
SSP 7.1 • Setup and Control Software
7.1 Setup
2 Sec
Right Back
channel
2 Sec
Left Back
channel
2 Sec
