Listening mode Number
of signal
channels
Dolby Digital Pro 6.0 to 7.1
Logic IIx Music
Dolby Digital Pro 6.0 to 7.1
Logic IIx Movie
DTS + Dolby EX or 6.0 to 6.1
DTS 96/24 + Dolby
EX
DTS + Dolby Pro 6.0 to 7.1
Logic IIx Music or
DTS 96/24 + Dolby
Pro Logic IIx Music
DTS + Dolby Pro 6.0 to 7.1
Logic IIx Movie or
DTS 96/24 + Dolby
Pro Logic IIx Movie
Types of channels
• Dependent on
configuration:
5 discrete, full-bandwidth
channels (L/R, C, LS/RS)
• 1 or 2 matrixed,
full-bandwidth channel (CB
or LB/RB)
•
1 discrete LFE channel (LFE)
• Dependent on
configuration:
5 discrete, full-bandwidth
channels (L/R, C, LS/RS)
•
1 or 2 matrixed,
full-bandwidth channels (CB
or LB/RB)
•
1 discrete LFE channel (LFE)
•
5 discrete, full-bandwidth
channels (L/R, C, LS/RS)
•
1 matrixed, full-bandwidth
channel (CB)
•
1 discrete LFE channel (LFE)
• Dependent on
configuration:
5 discrete, full-bandwidth
channels (L/R, C, LS/RS)
•
1 or 2 matrixed,
full-bandwidth channel (CB
or LB/RB)
•
1 discrete LFE channel (LFE)
•
Dependent on
configuration:
5 discrete, full-bandwidth
channels (L/R, C, LS/RS)
• 1 or 2 matrixed,
full-bandwidth channels (CB
or LB/RB)
• 1 discrete LFE channel (LFE)
SSP 7.1 • Reference Material
Media used
•
All DVDs
• Some broadcast HDTV
•
Some DBS
• All DVDs
•
Some broadcast HDTV
• Some DBS
•
Some DVDs that are
encoded with DTS Digital
Surround or DTS 96/24
•
Uses Dolby Digital matrix
processing techniques
to produce Center Back
channel information
• Some DVDs that
are encoded with
DTS Digital Surround or
DTS 96/24
•
Some DVDs that
are encoded with
DTS Digital Surround or
DTS 96/24
