D-4 Installing Windows Server 2008 R2
NOTE:
boot partition by Windows OS.
Example:
If you make a partition of 40,960MB (40GB), usable space will be
40,960MB – 100MB = 40,860MB.
The partition size required for a system with an installed memory size of 1GB(1,024MB) and a full
installation of the operating system:
8,000MB + (1,024MB * 1.5) + (1,024MB + 300MB) + application size
= 10,860MB + application size.
If the provided partition size is smaller than that required to install the OS and paging file, expand
the partition size or utilize a larger disk. If your system does not have a sufficient dump file size,
divide the required file space into multiple disks by performing the steps below:
1.
Set the system partition size to a size sufficient to install the OS and paging file.
2.
See "Setting for Solving Problems" to write the debug information of the dump file onto
another disk.
If there is not enough disk space to write the debug information, add another disk for the dump file.

BitLocker

If you use BitLocker, note the following:
Be sure to keep the recovery password secure. Do not keep it around a server running
BitLocker.
IMPORTANT:
operating system and see the partition content encrypted by BitLocker.
The recovery password may be needed when you start the operating
system after performing the following tasks:
– Replacing the motherboard
– Initializing the TPM
– Changing the BIOS setting
When new partition is created, initial 100MB is assigned as
Without the recovery password, you cannot start the
