NEC Express5800 User Manual page 327

Product name
PCI slot capability(*3) x16 lane
N code
PCI board type
Available board size
SCSI controller
N8103-95
(64-bit/66MHz PCI)
SCSI controller
N8103-75
(64-bit/133MHz PCI-X)
SCSI controller
N8103-107
(PCI EXPRESS (x1))
SAS controller
N8103-104A
(PCI EXPRESS(x8))
SAS controller
N8103-142
(PCI EXPRESS(x8))
RAID Controller
N8103-109 (128MB, RAID 0/1/5/6)
(PCI EXPRESS (x8))
RAID Controller
N8103-116A (128MB, RAID 0/1)
(PCI EXPRESS (x8))
RAID Controller
N8103-117A (128MB, RAID 0/1/5/6)
(PCI EXPRESS (x8))
100BASE-TX adapter
N8104-111
(32-bit/33MHz PCI)
1000BASE-T adapter
N8104-119
(64-bit/133MHz PCI-X)
1000BASE-T adapter (2 ch)
N8104-120
(64-bit/133MHz PCI-X)
1000BASE-T adapter
N8104-126
(PCI EXPRESS (x1))
1000BASE-T adapter (2ch)
N8104-121
(PCI EXPRESS (x4))
1000BASE-T adapter (4ch)
N8104-125A
(PCI EXPRESS (x4))
1000BASE-SX adapter (2ch)
N8104-112
(64-bit/133MHz PCI-X)
Additional RS232C
N8117-01A
connector kit
√: Available, –: Unavailable
*1 Lane: Indicates the transfer capability (transfer bandwidth). Example: 1 lane = 2.5 Gbps
(unidirectional), 4 lanes = 10 Gbps (unidirectional)
Socket: Indicates the connector size. A card that has the socket number or less can be connected.
Example: For a x4 socket, a x1 card or x4 card can be inserted. A x8 card cannot be inserted.
*2 The N8117-01A additional RS-232C connector kit comes with two types of cables. This
equipment uses "RS-232C cable (B)".
*3 Boards that are up to 173.1 mm long can be inserted into PCI slots 1, 2, and 3, and boards that
are up to 312 mm long can be inserted into PCI slot 4.
Slots to install the PCI board
PCI #1
Slot size
x16
socket
Short
–
–
–
√
√
√
√
√
–
–
–
√
√
√
–
√
PCI #2 PCI #3 PCI #4
32-bit/
x4 lane x2 lane
33MHz
Full-height
x8 x4
5V
socket socket
Short Long
√
– –
√
– –
√ √
–
√ √
–
√ √
–
√
– –
√
– –
√
– –
√
– –
√
– –
√
– –
√ √
–
√ √
–
√ √
–
√
– –
√ √ √
Upgrading Your Server 9-37
Remarks
–
Cannot co-exist with N8103-107.
Cannot co-exist with N8103-75.
Cannot connect to internal HDD.
–
–
–
–
Teaming with another NIC (FEC/GEC)
is not allowed.
Teaming with an identical AFT/ALB is
possible when using a standard
network with the following optional
LAN boards.
Teaming with another N8104-121 is
allowed.
Teaming with any other NIC is not
allowed.
Cannot co-exist with N8104-112.
1 max.
Cannot co-exist with N8103-110/120.
Teaming with any other NIC is not
allowed.
Cannot co-exist with N8104-112.
1 max.
Cannot co-exist with
N8104-119/126/120/121/125.
1 max.
