xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
TFTP Server IP
Destination File
Source File
Click Upload to initiate the upload.

Download Configuration

The following window is used to download the configuration file for the Switch.
Download Configuration From TFTP
This page allows the user to download the configuration file from a TFTP Server to the Switch and updates the switch.
Figure 12-10 Download Configuration – TFTP window (SI Mode Only)
Figure 12-11 Download Configuration – TFTP window (EI Mode Only)
The fields that can be configured are described below:
Parameter
Unit
Description
Use the drop-down menu to select a unit for uploading the firmware.
Enter the TFTP server IP address used.
IPv4(EI Mode Only)
IPv6 (EI Mode Only)
Enter the location and name of the Destination File.
Enter the location and name of the Source File.
Description
Use the drop-down menu to select a unit for receiving the configuration file. Select All for all
units.
Click the radio button to enter the TFTP server IP address used.
Click the radio button to enter the TFTP server IPv6 address used.
