xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter Description
Baud Rate Specify the baud rate for the serial port on the Switch. There are four possible baud rates to
choose from, 9600, 19200, 38400 and 115200. For a connection to the Switch using the console
port, the baud rate must be set to 115200, which is the default setting.
Auto Logout
Select the logout time used for the console interface. This automatically logs the user out after
an idle period of time, as defined. Choose from the following options: 2, 5, 10, 15 minutes or
Never. The default setting is 10 minutes.
Data Bits Display the data bits used for the serial port connection.
Parity Bits Display the parity bits used for the serial port connection.
Stop Bits Display the stop bits used for the serial port connection.
Click the Apply button to implement changes made.

Warning Temperature Settings

This window allows the user to configure the system warning temperature parameters.
To view the following window, click System Configuration > Warning Temperature Settings, as show below:
The fields that can be configured are described below:
Parameter Description
Traps State Use the drop-down menu to enable or disable the traps state option of the warning temperature
setting.
Log State Use the drop-down menu to enable or disable the log state option of the warning temperature
setting.
Figure 2-9 Serial Port Settings window
Figure 2-10 Warning Temperature Settings window
14
