xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
Click the Delete button to remove the specific entry.
Click the Delete All button to remove all the entries listed.
NOTE: When there is no matching server found for the packet based on option 60, the relay servers will
be determined by the default relay server setting.

DHCP Relay Option 60 Settings

This option decides whether the DHCP Relay will process the DHCP option 60 or not
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Option 60 Settings as
shown below:
The fields that can be configured are described below:
Parameter
String
Server IP
Match Type
IP Address
String
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete button to remove the specific entry based on the information entered.
Click the Show All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
Click the Delete button to remove the specific entry.
Figure 9-6 DHCP Relay Option 60 Settings window
Description
Enter the DHCP Relay Option 60 String value. Different strings can be specified for the
same relay server, and the same string can be specified with multiple relay servers. The
system will relay the packet to all the matching servers.
Here the user can enter the DHCP Relay Option 60 Server IP address.
Here the user can enter the DHCP Relay Option 60 Match Type value.
Exact Match – The option 60 string in the packet must full match with the specified string.
Partial Match – The option 60 string in the packet only need partial match with the
specified string.
Enter the DHCP Relay Option 60 IP address.
Enter the DHCP Relay Option 60 String value.
273
