The user may click the Infinite times radio button, in the Repeat Pinging for field, which will tell the ping program to
keep sending ICMP Echo packets to the specified IP address until the program is stopped. The user may opt to choose
a specific number of times to ping the Target IP Address by clicking its radio button and entering a number between 1
and 255.
The fields that can be configured are described below:
Parameter
Target IP Address
Repeat Pinging for
Size (EI Mode Only)
Timeout
Click the Start button to initiate the Ping Test.
Figure 11-23 Ping Test window (SI Mode Only)
Figure 11-24 Ping Test window (EI Mode Only)
Description
Enter an IP address to be pinged.
Enter the number of times desired to attempt to Ping either the IPv4 address or the IPv6
address configured in this window. Users may enter a number of times between 1 and
255.
For IPv6 only, enter a value between 1 and 6000. The default is 100.
Select a timeout period between 1 and 99 seconds for this Ping message to reach its
destination. If the packet fails to find the IP address in this specified time, the Ping
packet will be dropped.
