xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
To view the following window, click QoS > DSCP > DSCP Map Settings and select DSCP DSCP from the DSCP Map
drop-down menu, as show below:
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
DSCP Map
DSCP List
Figure 6-8 DSCP Map Settings - DSCP Priority window
Figure 6-9 DSCP Map Settings - DSCP DSCP window
Description
Select the unit you want to configure.
Use the drop-down menu to select a range of port to configure.
Use the drop-down menu to select one of two options:
DSCP Priority – Specifies a list of DSCP values to be mapped to a specific priority.
DSCP DSCP – Specifies a list of DSCP value to be mapped to a specific DSCP.
Enter a DSCP List value.
149
