xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
Dot1 TLV PVID
Dot1 TLV Protocol VLAN
Dot1 TLV VLAN
Dot1 TLV Protocol
Identity
Click the Apply button to accept the changes made.
Figure 4-85 LLDP Dot1 TLVs Settings window
Description
Select the starting and ending ports to use.
Use the drop-down menu to select the port range to use for this configuration.
Use the drop-down menu to enable or disable and configure the Dot1 TLV PVID
option.
Use the drop-down menu to enable or disable, and configure the Dot1 TLV Protocol
VLAN option. After enabling this option to the user can select to use either VLAN
Name, VID List or All in the next drop-down menu. After selecting this, the user can
enter either the VLAN Name or VID List value in the space provided.
Use the drop-down menu to enable or disable, and configure the Dot1 TLV VLAN
option. After enabling this option to the user can select to use either VLAN Name, VID
List or All in the next drop-down menu. After selecting this, the user can enter either
the VLAN Name or VID List value in the space provided.
Use the drop-down menu to enable or disable, and configure the Dot1 TLV Protocol
Identity option. After enabling this option the user can select to either use EAPOL,
LACP, GVRP, STP, or All.
129
