D-Link xStack Reference Manual page 266

xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
by the Administrator. A maximum of eight Enable Method Lists can be implemented on the Switch, one of which is a
default Enable Method List. This default Enable Method List cannot be deleted but can be configured.
The sequence of methods implemented in this command will affect the authentication result. For example, if a user
enters a sequence of methods like TACACS - XTACACS - Local Enable, the Switch will send an authentication request
to the first TACACS host in the server group. If no verification is found, the Switch will send an authentication request
to the second TACACS host in the server group and so on, until the list is exhausted. At that point, the Switch will
restart the same sequence with the following protocol listed, XTACACS. If no authentication takes place using the
XTACACS list, the Local Enable password set in the Switch is used to authenticate the user.
Successful authentication using any of these methods will give the user an "Admin" privilege.
NOTE: To set the Local Enable Password, see the next section, entitled Local Enable Password.
To view this window, click Security > Access Authentication Control > Enable method Lists Settings as shown
below:
To delete an Enable Method List defined by the user, click the Delete button corresponding to the entry desired to be
deleted. To modify an Enable Method List, click on its corresponding Edit button.
The fields that can be configured are described below:
Parameter
Method List Name
Priority 1, 2, 3, 4
Figure 8-63 Enable method Lists Settings window
Description
Enter a method list name defined by the user of up to 15 characters.
The user may add one, or a combination of up to four of the following authentication
methods to this method list:
local_enable - Adding this parameter will require the user to be authenticated using the
local enable password database on the Switch. The local enable password must be set
by the user in the next section entitled Local Enable Password.
none - Adding this parameter will require no authentication needed to access the Switch.
radius - Adding this parameter will require the user to be authenticated using the
RADIUS protocol from a remote RADIUS server.
tacacs - Adding this parameter will require the user to be authenticated using the
TACACS protocol from a remote TACACS server.
xtacacs - Adding this parameter will require the user to be authenticated using the
XTACACS protocol from a remote XTACACS server.
tacacs+ - Adding this parameter will require the user to be authenticated using the
257
