xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
Click the Apply button to accept the changes made for each individual section.
NOTE: A successful authentication should direct the client to the stated web page. If the client does not
reach this web page, yet does not receive a Fail! Message, the client will already be authenticated
and therefore should refresh the current browser window or attempt to open a different web page.

WAC User Settings

Users can view and set local database user accounts for Web authentication.
To view this window, click Security > Web-based Access Control (WAC) > WAC User Settings as shown below:
The fields that can be configured are described below:
Parameter
User Name
VLAN Name
VID (1-4094)
Password
Confirmation
Click the Apply button to accept the changes made.
Click the Delete All button to remove all the entries listed.
Click the Edit VLAN Name button to re-configure the specific entry's VLAN Name.
Click the Edit VID button to re-configure the specific entry's VLAN ID.
Click the Clear VLAN button to remove the VLAN information from the specific entry.
Click the Delete button to remove the specific entry.

WAC Port Settings

Users can view and set port configurations for Web authentication.
HTTPS – Specifies that the TCP port will run the WAC HTTPS protocol. The default
value is 443. HTTPS cannot run at TCP port 80.
Figure 8-38 WAC User Settings window
Description
Enter the user name of up to 15 alphanumeric characters of the guest wishing to access
the Web through this process. This field is for administrators who have selected Local as
their Web-based authenticator.
Click the button and enter a VLAN Name in this field.
Click the button and enter a VID in this field.
Enter the password the administrator has chosen for the selected user. This field is case-
sensitive and must be a complete alphanumeric string. This field is for administrators who
have selected Local as their Web-based authenticator.
Retype the password entered in the previous field.
234
