xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
Click the View All button to display all the existing entries.
Click the Group List link to configure the Multicast Group Profile Multicast Address Settings for the specific entry.
Click the Delete button to remove the specific entry.
After clicking the Group List
Figure 4-68 Multicast Group Profile Multicast Address Settings window
The fields that can be configured are described below:
Parameter
Multicast Address List
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to discard the changes made and return to the previous page.
Click the Delete button to remove the specific entry.

MLD Snooping Multicast VLAN Settings

Users can add, delete, or configure the MLD snooping multicast VLAN on this page.
To view the following window, click L2 Features > L2 Multicast Control > Multicast VLAN > MLD Snooping
Multicast Group VLAN Settings, as show below:
The fields that can be configured are described below:
Parameter
MLD Multicast VLAN
State
link, the following page will appear:
Description
Enter the multicast address list.
Figure 4-69 MLD Snooping Multicast VLAN Settings window
Description
Click the radio buttons to enable or disable the MLD multicast VLAN state.
116
