xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide
Figure 11-9 TX Packets Analysis window (table for Bytes and Packets)
The fields that can be configured are described below:
Parameter
Port
Time Interval
Record Number
Bytes
Packets
Unicast
Multicast
Broadcast
Show/Hide
Click the Apply button to accept the changes made for each individual section.
Click the Clear button to clear all statistics counters on this window.
Click the View Table link to display the information in a table rather than a line graph.
Click the View Graphic link to display the information in a line graph rather than a table.

Errors

The Web manager allows port error statistics compiled by the Switch's management agent to be viewed as either a line
graph or a table. Four windows are offered.
Description
Use the drop-down menu to choose the port that will display statistics.
Select the desired setting between 1s and 60s, where "s" stands for seconds. The
default value is one second.
Select number of times the Switch will be polled between 20 and 200. The default value
is 200.
Counts the number of bytes successfully sent on the port.
Counts the number of packets successfully sent on the port.
Counts the total number of good packets that were transmitted by a unicast address.
Counts the total number of good packets that were transmitted by a multicast address.
Counts the total number of good packets that were transmitted by a broadcast address.
Check whether or not to display Bytes and Packets.
